    GTM21 • Metric and Metric Fine • Through Coolant

    Victory™ Solid Carbide Thread Mills • Blind and Through Holes

    Material Number4138515

    ISO Catalog IDGTM215002ANSI Catalog IDGTM215002

    GTM21 Thru Cool M/MF Tapping - 4138515 - WIDIA
    GTM21 Thru Cool M/MF Tapping - 4138515 - WIDIA
    GTM21 Thru Cool M/MF Tapping - 4138515 - WIDIA
    Open expanded view
    GTM21 Thru Cool M/MF Tapping - 4138515 - WIDIA
    GTM21 Thru Cool M/MF Tapping - 4138515 - WIDIA
    Generic representation
    List Price
    C$383.06/each
    Discount
    Your Price
    /each
    In StockThis item is no longer availableLonger Delivery
    Material Pricing Group
    Contact our sales team to discover all of your pricing options
    Sold in pkg. of 0Adjusted to meet the minimum package size.
    Minimum qty: 0Adjusted to meet the minimum quantity requirement.
    This item is no longer available
    • Threading: Through HoleThreading: Through Hole
    • Threading: Blind HoleThreading: Blind Hole
    • Counter Sinking/ Stroke ChamferingCounter Sinking/ Stroke Chamfering
    • Through Coolant: Axial: TappingThrough Coolant: Axial: Tapping
    • HMHM
    • Manufacturer’s Specs: MManufacturer’s Specs: M
    • Manufacturer’s Specs: MFManufacturer’s Specs: MF
    • Drilling Depth: 2xDrilling Depth: 2x
    {{cadTool}} format is not available

    Sending to {{cadTool}} in progress...

    Downloaded file will be available after import in the {{cadTool}} tool library.

    Drawings for 4138515
    Metric
    Inch
    Material Number4138515
    ISO Catalog IDGTM215002
    ANSI Catalog IDGTM215002
    GradeWU12PV
    [TDZ] Thread Diameter SizeM6X1
    [D1] Effective Cutting Diameter4.8 mm
    [D1] Effective Cutting Diameter0.189 in
    [DCH] Chamfer Diameter 6.3 mm
    [DCH] Chamfer Diameter 0.248 in
    [LTHD] Thread Length 12.52 mm
    [LTHD] Thread Length 0.4929 in
    [LDCH] Chamfer Length-Tool Front 13.19 mm
    [LDCH] Chamfer Length-Tool Front 0.5193 in
    [L] Overall Length 62 mm
    [L] Overall Length 0.2447 in
    [LS] Shank Length 36 mm
    [LS] Shank Length 1.4173 in
    [D] Adapter / Shank / Bore Diameter8 mm
    [D] Adapter / Shank / Bore Diameter0.315 in
    Number of Effective Cutting Edges on Face3
    See all Product Variants

    Uses and application

    • Threading: Through HoleThreading: Through Hole
    • Threading: Blind HoleThreading: Blind Hole
    • Counter Sinking/ Stroke ChamferingCounter Sinking/ Stroke Chamfering
    • Through Coolant: Axial: TappingThrough Coolant: Axial: Tapping
    • HMHM
    • Manufacturer’s Specs: MManufacturer’s Specs: M
    • Manufacturer’s Specs: MFManufacturer’s Specs: MF
    • Drilling Depth: 2xDrilling Depth: 2x

    Grades

    WU12PV

    WU12PV

    Coated carbide. PVD fine-grain carbide substrate with high-hardness TiCN coating.
    Universal grade for thread milling most materials.

    Create Solution to calculate Feeds and Speeds

    After creating a solution just choose the Feeds & Speeds icon and our system will provide recommendations. You can customize the information by adding your machine and specifications or make adjustments using the sliders.
