| Product # | 5077681 |
| ISO Catalog Number | A12MSCLPR06 |
| ANSI Catalog Number | A12MSCLPR06 |
| Grade | WG |
| [D]Adapter/Shank/Bore Dia Inch | .47 |
| [DMIN]Min BoreDia_Ax GrvDia In | .6300 |
| [F] F Dimension Inch | .3540 |
| [L1] Tool Length Inch | 5.906 |
| [A]Coolant Hole Dia Inch | .1600 |
| [GAMMAF] Radial Rake Angle | -3.000 |
| Catalog Gage Insert 1 | CP..06 |
| Insert Screw ID Drive Size | T7 |
| Product # | ISO Catalog Number | ANSI Catalog Number | Grade | [D]Adapter/Shank/Bore Dia Inch | [DMIN]Min BoreDia_Ax GrvDia In | [F] F Dimension Inch | [L1] Tool Length Inch | [L2] Head Length Inch | [A]Coolant Hole Dia Inch | [CS] Coolant Supply Size | [GAMMAF] Radial Rake Angle | Catalog Gage Insert 1 | Insert Screw ID Drive Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5077616 | A06MSCLPL2 | A06MSCLPL2 | WG | .375 | .4800 | .2500 | 6 | .1250 | -6.000 | CP..21 | T7 | ||
| 5077618 | A06MSCLPR2 | A06MSCLPR2 | WG | .375 | .4800 | .2500 | 6 | .1250 | -6.000 | CP..21 | T7 | ||
| 5077643 | A08RSCLPR2 | A08RSCLPR2 | WG | .5 | .6000 | .3120 | 8 | .1560 | 1/16-27 NPT | -3.000 | CP..21 | T7 | |
| 5077645 | A10KSCLPR06 | A10KSCLPR06 | WG | .39 | .5120 | .2760 | 4.921 | .1300 | -4.000 | CP..06 | T7 | ||
| 5077648 | A10SSCLPR2 | A10SSCLPR2 | WG | .625 | .7700 | .4060 | 10 | 1/8-27 NPT | -2.000 | CP..21 | T7 | ||
| 5077649 | A10SSCLPR3 | A10SSCLPR3 | WG | .625 | .7700 | .4060 | 10 | 1.090 | .1560 | 1/8-27 NPT | -2.000 | CPMT3252 | T15 |
| 5077680 | A12MSCLPL06 | A12MSCLPL06 | WG | .47 | .6300 | .3540 | 5.906 | .1600 | -3.000 | CP..06 | T7 | ||
| 5077681 | A12MSCLPR06 | A12MSCLPR06 | WG | .47 | .6300 | .3540 | 5.906 | .1600 | -3.000 | CP..06 | T7 | ||
| 5077682 | A12SSCLPL3 | A12SSCLPL3 | WG | .75 | .9300 | .5000 | 10 | 1/8-27 NPT | -2.000 | CP..32 | T15 | ||
| 5077686 | A12SSCLPR3 | A12SSCLPR3 | WG | .75 | .9300 | .5000 | 10 | 1/8-27 NPT | -2.000 | CP..32 | T15 | ||
| 5077694 | A16RSCLPR06 | A16RSCLPR06 | WG | .63 | .7870 | .4330 | 7.874 | 1/8-27 NPT | -5.000 | CC..06 | T7 | ||
| 5077699 | A16TSCLPR3 | A16TSCLPR3 | WG | 1.0 | 1.200 | .6400 | 12 | 1/4-18 NPT | .000 | CP..32 | T15 |
