WIDIA is a leading manufacturer of indexable face-milling solutions. Designed to cut the surface of a workpiece perpendicularly, WIDIA face mills are a great choice for a wide range of machining applications including roughing, semi-finishing and finishing. Each platform offers first-choice capabilities and effective cutting-edges that reduce overall costs in your shop. Dedicated to value and versatility, WIDIA's face mills deliver the performance and results necessary to get the job done. Choose from a full offering of WIDIA face-milling solutions including the M640, SuperFeed PCD and M1600.
Filters
Filters
View filters in
MetricInch
Workpiece Material
Workpiece Material
- P Steel (384)
- P0Low-Carbon Steels, Long Chipping C < .25%; <125 HB; <530 N/mm^2 UTS(349)
- P1Low-Carbon Steels, Short Chipping C < .25%; <125 HB; <530 N/mm^2 UTS(384)
- P2Medium and High Carbon Steels C < .25%; <220 HB; <25 HRC; >530 N/mm^2 UTS(384)
- P3Alloy Steels & Tool Steels C > .25%; <330 HB; <35 HRC; 600-850 N/mm^2 UTS(384)
- P4Alloy Steels & Tool Steels C > .25%; 350-420 HB; 35-43 HRC; 850-1400 N/mm^2 UTS(384)
- P5Ferritic, Martensitic, and PH Stainless Steels <330 HB; <35 HRC; 600-900 N/mm^2 UTS(383)
- P6High Strength Ferritic, Martensitic, and PH Stainless Steels 350-450 HB; 35-43 HRC; 900-2400 N/mm^2 UTS(383)
- M Stainless Steel (383)
- M1Austenitic Stainless Steel 130-200 HB; <600 N/mm^2 UTS(383)
- M2High Strength Austenitic Stainless and Cast Stainless Steels 150-230 HB; <25 HRC; >600 N/mm^2 UTS(383)
- M3Duplex Stainless Steel 135-275 HB; <30 HRC; 500-1200 N/mm^2 UTS(383)
- K Cast Iron (431)
- K1Gray Cast Iron 120-290 HB; <32 HRC; 125-500 N/mm^2 UTS(431)
- K2Low and Medium Strength CGI and Ductile Irons 130-260 HB; <28 HRC; <600 N/mm^2 UTS(427)
- K3High Strength Ductile and Austempered Ductile Iron 180-350 HB; <43 HRC; >600 N/mm^2 UTS(427)
- N Non-Ferrous Materials (304)
- N1Wrought Aluminum (304)
- N2Low-Silicon Aluminum Alloys and Magnesium Alloys Si <12.2%(304)
- N3High-Silicon Aluminum Alloys Si >12.2%(304)
- S High-Temp Alloys (369)
- S1Iron-Based, Heat-Resistant Alloys 160-260 HB; 25-48 HRC; 500-1200 N/mm^2 UTS(323)
- S2Cobalt-Based, Heat-Resistant Alloys 250-450 HB; 25-48 HRC; 1000-1450 N/mm^2 UTS(323)
- S3Nickel-Based, Heat Resistant Alloys 160-450 HB; <48 HRC; 600-1700 N/mm^2 UTS(323)
- S4Titanium and Titanium Alloys 300-400 HB; 33-43 HRC; 900-1600 N/mm^2 UTS(369)
- H Hardened Materials (263)
- H1Hardened Materials 44-48 HRC(263)
Select All Star
