Top Cut 4™

Top Cut 4™ is a versatile indexable drill  with four true cutting edges on each insert. This drill is capable of supporting a variety of applications including through and cross-hole, inclined entry and exit, 45 degree corner,  half cylindrical, concave, blind, and chain drilling.

Top Cut 4 is an All-Star tool.

Order tools with same-day shipping with All-Star! Learn more.

Three Chip Breakers in Four Grades

-V34

First choice for machining steel, cast iron and short chipping materials. Suitable for severe cutting conditions.

-V36

This insert is suitable for situations with low power consumption. First choice for universal use.

-V38

First choice for long chipping materials in titanium and stainless steel.



Product Features:

  • Standard diameter range covering 12-68mm
  • 4 real cutting edges per insert
  • 4 grades to achieve higher tool life at accelerated speeds: WU25CH, WU40PH, WPK10CH, WN10PH
  • X-offset design to adjust diameter size on turning machines and optimize tolerances on machining centers
  • Coolant channels exit right behind the cutting edge
  • Differentiated insert shapes to avoid grade mixing between central and periphery inserts
  • Optimized flutes to contain chips during machining
  • Flanged shank to increase the overall drill stability in deep-drilling applications
