VT-SPO • Form B Plug Chamfer • Machine Screw and Fractional • ANSI

Name: VT-SPO • Form B Plug Chamfer • Machine Screw and Fractional • ANSI
SKU: 5357263

VT-SPO • Form B Plug Chamfer • ANSI

Metric

Inch

Codice materiale SAP	5357263
Codice catalogo ISO	VTSPO5006
Codice catalogo ANSI	VTSPO5006
Qualità	WP49EG
[D1-TDZ] Dimensione diametro filetto	4 - 40
[L] Lunghezza complessiva	47.7000 mm
[L] Lunghezza complessiva	1.880 in
[L3] Lunghezza filettata	13.0000 mm
[L3] Lunghezza filettata	.5100 in
[L2] Lunghezza utilizzabile	17.6000 mm
[L2] Lunghezza utilizzabile	.6900 in
[D] Dia adattatore / stelo / foro	3.581 mm
[D] Dia adattatore / stelo / foro	.141 in
[Z] Numero di vani	2
Limite diametro primitivo maschio	H3

See all Product Variants

Uses and application

Maschiatura: Foro passante
HSS-E
Refrigerante esterno: Maschiatura
Specifiche del costruttore: ANSI
Specifiche del costruttore: UNC
Specifiche del costruttore: UNF
Multipurpose Taps: Spiral Point
Codolo — R8 Bridgeport

Workpiece Materials

P Acciaio

M Acciai inossidabili

K Ghisa

Features and benefits

WP42EG TiCN

WU41EG TiN

WP49EG oxide

WU40EG bright

Grades

WP49EG

Substrato HSS-E vaporizzato. Da usare per una varietà di materiali fra cui acciaio, acciaio inossidabile e ghisa duttile. Non raccomandato per i materiali non ferrosi.

P Acciaio

K Ghisa

M Acciai inossidabili

Application Data • HSS-E • Inch

		<="" td="">					<="" td="" />
		Otwory przelotowe					Otwory nieprzelotowe
				Zakres prędkości skrawania [SFM]					Zakres prędkości skrawania [SFM]
Grupa materiałowa		Typ gwintownika	Gatunek	min.	Wartość początkowa	maks.	Typ gwintownika	Gatunek	min.	Wartość początkowa	maks.
P	1	VT-SPO	WP42EG, WU41EG	70	90	110	VT-SFT	WP42EG, WU41EG	40	60	90
		VT-SPO	WP49EG, WU40EG	30	45	60	VT-SFT	WP49EG, WU40EG	20	30	40
	2,3,4,5	VT-SPO	WP42EG, WU41EG	50	70	90	VT-SFT	WP42EG, WU41EG	40	50	70
		VT-SPO	WP49EG, WU40EG	30	35	40	VT-SFT	WP49EG, WU40EG	10	20	30
	6,7,8,10	VT-SPO	WP42EG, WU41EG	30	40	50	VT-SFT	WP42EG, WU41EG	20	30	40
		VT-SPO	WP49EG, WU40EG	20	20	30	VT-SFT	WP49EG, WU40EG	10	10	10
		VT-STR NPT	WU41EG	20	20	30	VT-STR NPT	WU41EG	20	20	30
		VT-STR NPT	WU40EG	10	10	10	VT-STR NPT	WU40EG	10	10	10
M	14.1, 14.3	VT-SPO	WP42EG, WU41EG	30	40	50	VT-SFT	WP42EG, WU41EG	20	30	40
		VT-SPO	WP49EG, WU40EG	20	20	30	VT-SFT	WP49EG, WU40EG	10	10	10
		VT-SFT NPT	WU41EG	20	20	30	VT-SFT NPT	WU41EG	20	20	30
		VT-SFT NPT	WP49EG, WU40EG	10	10	10	VT-SFT NPT	WP49EG, WU40EG	10	10	10
	14.2	VT-SPO	WP42EG, WU41EG	20	30	40	VT-SFT	WP42EG, WU41EG	10	20	30
		VT-SPO	WP49EG, WU40EG	10	15	20	VT-SFT	WP49EG, WU40EG	7	10	10
K	15,16	VT-STR NPT	WU41EG	30	45	60	VT-STR NPT	WU41EG	30	45	60
		VT-STR NPT	WU40EG	20	25	30	VT-STR NPT	WU40EG	20	25	30
	17,18,19	VT-SPO	WP42EG, WU41EG	70	90	110	VT-SFT	WP42EG, WU41EG	40	60	90
		VT-SPO	WP49EG, WU40EG	30	45	60	VT-SFT	WP49EG, WU40EG	20	30	40
N	21,22	VT-SPO	WP42EG, WU41EG	110	150	190	VT-SFT	WP42EG, WU41EG	80	110	160
		VT-SPO	WU40EG	60	75	90	VT-SFT	WU40EG	40	50	72
	23,24	VT-SPO	WP42EG, WU41EG	100	130	160	VT-SFT	WP42EG, WU41EG	60	90	130
		VT-SPO	WU40EG	50	65	80	VT-SFT	WU40EG	40	50	70
	26,27,28	VT-SPO	WP42EG, WU41EG	23	30	40	VT-SFT	WP42EG, WU41EG	10	20	30
		VT-SPO	WU40EG	10	15	20	VT-SFT	WU40EG	10	10	10

Application Data • HSS-E-PM • Inch

Grupa materiałowa		<="" td="">					<="" td="" />
		Otwory przelotowe					Otwory nieprzelotowe
				Zakres prędkości skrawania [SFM]					Zakres prędkości skrawania [SFM]
		Typ gwintownika	Gatunek	min.	Wartość początkowa	maks.	Typ gwintownika	Gatunek	min.	Wartość początkowa	maks.
P	P1	GT20	GP6520	70	100	150	GT30, GT32, GT50	GP6520	50	70	100
	P1	GT24	WU32MG	70	100	150	GT24, GT26	WU32MG	50	70	100
	P2	GT20	GP6520	50	80	120	GT30, GT32, GT50	GP6520	40	60	90
	P2	GT24	WU32MG	50	80	120	GT24, GT26	WU32MG	40	60	90
	P3	GT20	GP6520	40	50	60	GT30, GT32, GT50	GP6520	30	30	40
	P4	GT00	WP31MG	15	20	26	GT02, GT04	WP31MG	11	14	18
	P5	GT20	GP6520	40	50	60	GT30, GT32, GT50	GP6520	30	30	40
	P6	GT00	WP31MG	20	30	30	GT02, GT04	WP31MG	10	20	20
M	M1	GT20	GM6515	40	50	60	GT30, GT32, GT50	GM6515	30	30	40
	M1	GT24	WU32MG	20	30	40	GT24, GT26	WU32MG	10	20	30
	M2	GT20	GM6515	30	40	50	GT30, GT32, GT50	GM6515	20	30	40
	M3	GT00	WP31MG	10	20	20	GT02, GT04	WP31MG	10	10	10
K	K1	GT40	GP6520	90	110	150	GT40, GT42	GP6520	60	80	100
K	K2	GT40	GP6520	80	100	130	GT40, GT42	GP6520	50	70	90
N	N1	GT72	WN44EG	110	160	210	GT82, GT86	WN44EG	80	110	150
	N1	GT22	WN48EG	120	180	230	GT22	WN48EG	80	130	160
	N2	GT40	GP6520	100	150	190	GT40, GT42	GP6520	70	100	130
		GT72	WN44EG	100	150	190	GT82, GT86	WN44EG	70	100	130
		GT22	WN38MG	110	160	210	GT22	WN38MG	80	110	150
	N4	GT40	GP6520	22	30	49	GT40, GT42	GP6520	15	23	34
S	S1	GT20	GP6520	30	40	60	GT30, GT32	GP6520	18	28	41
	S2, S3	GT90	WU32MG	11	16	25	GT92, GT94	WU32MG	8	11	17
	S2, S3	GT90	WS39MG	5	10	12	GT92, GT94	WS39MG	4	6	9
	S4	GT60	WS34MG	9	13	20	GT62	WS34MG	6	9	14
H	H1	GT06	WN35MG	4.4	6.6	9.8	GT06	WN35MG	3.1	4.6	6.9
H	H2	GT06	WN35MG	3.3	4.9	7.4	GT06	WN35MG	2.3	3.4	5.2
