WGC – Utensili di scanalatura e troncatura

Turning Grooving Icon

Scanalatura:

  • Prima scelta per applicazioni di scanalatura esterna sulla maggior parte dei materiali
  • Adduzione interna ed efficiente di refrigerante per una maggiore produttività
  • Larghezza di scanalatura 2-10 mm (0,084"-0,399")
Turning Profiling Icon

Profilatura:

  • Rompitrucioli a raggio completo per tornitura multidirezionale per la realizzazione di profili complessi
  • Il design rigido garantisce una finitura superficiale omogenea
  • 2-8 mm (0,079"-0,315")
