当需要稳定性和可靠性时,WIDIA™TOP DRILL™Modular X (TDMX) 是高要求钻孔应用的最佳选择。

Close up of the TDMX modular drill point
WIDIA TDMX modular drill insert


  • 标准刀体,具备 3 x D、5 x D 和 8 x D 长度。
  • 刀片直径范围为 0.629" - 1.574" (16mm - 40mm)。
  • 一种槽型和材质即可涵盖覆盖钢和铸铁应用。


  • 前固定设计。无需从刀柄上拆下刀体即可更换刀片。
  • 简单的刀片命名逻辑,便于识别目标材料组。


  • 高度工程化的刀槽座设计可确保最大的稳定性,即使在挑战性的应用中,例如,交叉孔、斜切进刀/退刀以及断续切削中也是如此。
  • 适合高进给率。
  • 法兰刀柄,刚性更强。
  • 抛光排屑槽可提高排屑能力。
  • 全新的 WP40PD 材质,可延长钢和铸铁应用中的刀具寿命。
Tube sheet with holes and WIDIA Shining Moments logo

TDMX - Tube Sheet Drilling

Material: Fe510/1.0553/A441

Condition: Rough Surface
