| SAP Material Number | 2004141 |
| ISO Catalog Number | 12627276800 |
| ANSI Catalog Number | 12627276800 |
| Grade | WG |
| [DM] Minimum Bore Diameter | 50.0000 mm |
| [DM] Minimum Bore Diameter | 1.968 in |
| [DMAX] Maximum Bore Diameter | 65.0000 mm |
| [DMAX] Maximum Bore Diameter | 2.559 in |
| [L1] Tool Length | 46.0000 mm |
| [L1] Tool Length | 1.811 in |
| [H] Shank Height | 12.0000 mm |
| [H] Shank Height | .4724 in |
| [H1] Cutting Height | 6.5000 mm |
| [H1] Cutting Height | .2559 in |
| [B] Shank Width | 12.0000 mm |
| [B] Shank Width | .4724 in |
| Gage Insert | TC../TP..1102.. |
| Torque Newton Meters | 1.000 |
| Torque Foot Pounds | 0.7400 |
Through Coolant: Axial: Drilling
