Kendex™ RNMN120300S02020 ISO/ANSI Turning Insert 3883275 - Widia
Product Similar To:
Cubic Boron Nitride (CBN) Inserts • RNMN/RNM
ISO/ANSI Inserts
Material Number3883275
ISO Catalog IDRNMN120300S02020ANSI Catalog IDRNM42S0820
List Price
₹27,193.00/each
Discount
Your Price
/each
In StockThis item is no longer availableLonger Delivery
Material Pricing Group
Sold in pkg. of 0Adjusted to meet the minimum package size.
Minimum qty: 0Adjusted to meet the minimum quantity requirement.
- K Cast Iron
Sending to {{cadTool}} in progress...
Downloaded file will be available after import in the {{cadTool}} tool library.
MetricInch
| Material Number | 3883275 |
| ISO Catalog ID | RNMN120300S02020 |
| ANSI Catalog ID | RNM42S0820 |
| Grade | WBH40C |
| [D] Insert IC Size | 12.7 mm |
| [D] Insert IC Size | 0.5 in |
| [S] Insert Thickness | 3.18 mm |
| [S] Insert Thickness | 0.125 in |
Workpiece Materials
- Cast Iron
Grades
WBH40C
A high CBN content, solid CBN with multiple cutting edges and a CVD — Al203-TiN-TiCN-Al203-TiN alumina coating. Applied in roughing to semi-finishing of fully pearlitic gray cast iron, chilled irons, high chrome alloy steels, sintered powdered metals, and heavy cuts in hardened steels (>45 HRC). Use for finished chilled and fully pearlitic cast iron. Do not apply on finishing hardened steels. The solid WBH40C also can be effectively applied when roughing hardened steels.
Create Solution to calculate Feeds and Speeds
After creating a solution just choose the Feeds & Speeds icon and our system will provide recommendations. You can customize the information by adding your machine and specifications or make adjustments using the sliders.
