| Material Number | 4170213 |
| ISO Catalog ID | DCMT11T312MP |
| ANSI Catalog ID | DCMT3253MP |
| Grade | WP15CT |
| [D] Insert IC Size | 9.525 mm |
| [D] Insert IC Size | 0.375 in |
| [L10] Insert Cutting Edge Length | 11.628 mm |
| [L10] Insert Cutting Edge Length | 0.4578 in |
| [S] Insert Thickness | 3.969 mm |
| [S] Insert Thickness | 0.1563 in |
| [Rε] Corner Radius | 1.2 mm |
| [Rε] Corner Radius | 0.047 in |
| [D1] Insert Hole Size | 4.4 mm |
| [D1] Insert Hole Size | 0.1732 in |
Grades
WP15CT
Coated carbide. MT-CVD/CVD — TiN-TiCN-Al2O3-ZrCN. Good balance of wear resistance
and toughness properties. High-productivity machining on smooth to lightly interrupted cuts. For steels.
