Balanced-by-Design
Shank - 5/8"–11 unc Drawbar
Drilling - Through Coolant
Shank - Cylindrical Weldon 2 Flat
Balance - G 6.3@15,000 min-1
Shank - Cylindrical Weldon DIN 1835/B
Shank - SK CAT(CV) Taper Face ContactDownloaded file will be available after import in the {{cadTool}} tool library.
| Material Number | 3860091 |
| ISO Catalog ID | CVKV40BEM038250 |
| ANSI Catalog ID | CVKV40BEM038250 |
| [D2] Body Diameter 1 Workpiece Side | 25.4 mm |
| [D2] Body Diameter 1 Workpiece Side | 1 in |
| [L1] Gage Length | 63.5 mm |
| [L1] Gage Length | 2.5 in |
| Gage Length Face Contact [L1FC] | 62.5 mm |
| Gage Length Face Contact [L1FC] | 2.4606 in |
| [L9] Clamping Length | 101.75 mm |
| [L9] Clamping Hole Length | 4.006 in |
| Clamp Screw ID Drive Size | 3/16 |
| Torque Catalog Foot Pounds | 15 |
| Weight Pounds | 2.36 |
| [D1] Adapter / Shank / Bore Diameter | 9.525 mm |
| [D1] Adapter / Shank / Bore Diameter | 0.375 in |
Balanced-by-Design Shank - 5/8"–11 unc DrawbarDrilling - Through CoolantShank - Cylindrical Weldon 2 FlatBalance - G 6.3@15,000 min-1Shank - Cylindrical Weldon DIN 1835/BShank - SK CAT(CV) Taper Face ContactDownload PDF Table with speeds and Feeds Data
