Threading: Through Hole
Threading: Blind Hole
Through Coolant: Axial: Tapping
HM
Manufacturer’s Specs: M
Manufacturer’s Specs: MF
Drilling Depth: 2xDownloaded file will be available after import in the {{cadTool}} tool library.
| Material Number | 4138511 |
| ISO Catalog ID | GTM115021 |
| ANSI Catalog ID | GTM115021 |
| Grade | WU13PV |
| [TDZ] Thread Diameter Size | M16X1.5 |
| [D1] Effective Cutting Diameter | 11.9 mm |
| [D1] Effective Cutting Diameter | 0.4685 in |
| [AP1MAX] 1st Maximum Cutting Depth | 32.16 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 1.2661 in |
| [L] Overall Length | 90 mm |
| [L] Overall Length | 3.5433 in |
| [LS] Shank Length | 45 mm |
| [LS] Shank Length | 1.7717 in |
| [D] Adapter / Shank / Bore Diameter | 12 mm |
| [D] Adapter / Shank / Bore Diameter | 0.4724 in |
| Number of Effective Cutting Edges on Face | 4 |
Threading: Through HoleThreading: Blind HoleThrough Coolant: Axial: TappingHMManufacturer’s Specs: MManufacturer’s Specs: MFDrilling Depth: 2xGrades
WU13PV
Coated carbide. PVD carbide substrate with heat-resistant TiAlN coating.
Universal grade for thread milling most materials.
