Axial Adjustment - End
Drilling - Through Coolant
Shank - Cylindrical Plain
Shank - Cylindrical Weldon
Shank - Cylindrical with SquareDownloaded file will be available after import in the {{cadTool}} tool library.
| Ürün Numarası | 1025637 |
| ISO Katalog No | SS100TG050698G |
| AISI Catalog No | SS100TG050698G |
| [CST] Catalog Collet Series | TG50 |
| [D11] Lock Nut Diameter | 38.1 mm |
| [D11] Lock Nut Diameter | 1.5 in |
| [L] Overall Length | 177.292 mm |
| [L] Overall Length | 6.98 in |
| [L2] Usable Length | 37.846 mm |
| [L2] Usable Length | 1.49 in |
| [L9] Clamping Length | 45 mm |
| [L9] Clamping Hole Length | 1.77 in |
| [V] Adjustment Range | 115 mm |
| [V] Adjustment Range | 4.53 in |
| Torque Catalog Foot Pounds | 50 |
| Stop Screw ID Drive Size | 4 mm & 5/32 |
| Weight Pounds | 1.15 |
| [D] Adapter / Shank / Bore Diameter | 25.4 mm |
| [D] Adapter / Shank / Bore Diameter | 1 in |
